Hydraulic Rock Splitter Quarry Stone Cutting Machine Concrete Block Splitter

Basic Info.

Model NO.	zm
Tank Capability(L)	40
Hole Diameter	32~38mm
Theoretical Splitting Force	500t
Piston Diameter	80mm
Transport Package	Carton Box, Plastic Bagsor as Your Payment
Specification	CE, SGS
Trademark	China Coal
Origin	China
HS Code	8465910000
Production Capacity	1000 Sets Per Month

Product Description

Introduction of Zm (32-38) Diesel Hydraulic Stone Rock Concrete Splitting Machine
Zm (32-38) Diesel Hydraulic Stone Rock Concrete Splitting Machine is our newly developed Product which is a powerful and extremely cost-effective alternative to other conventional demolition tools. It can develop a very huge splitting force (Maximum 1000 T) when it put into the pre- drill holes of rock or concrete and crack it into pieces within several seconds.zmwm07
Parameter of Zm (32-38) Diesel Hydraulic Stone Rock Concrete Splitting Machine

Model	Piston Diameter	Hole Diameter	Hole Depth	Length of wedge	crack width	Split time	Theoretical splitting force	actual split force
(Type)	(MM)	(MM)	(MM)	(MM)	(mm)	(S)	(T)	(T)
ZM( 32-38)A	80	Φ32~38	≥300	150	10~35	5~12	500	280
ZM( 38-40)A	80	Φ38~42	≥300	150	10~40	5~12	500	280
ZM( 38-40)B	80	Φ38~42	≥400	200/250	10~40	5~12	650/600	350/300
ZM( 40-42)	90	Φ42~46	≥600	300	10~40	5~12	680	420
ZM( 42-46)	90	Φ42~46	≥600	380	10~40	5~12	650	500
ZM( 44-46)A	100	Φ44~46	≥600	300/380	10~40	5~12	780	550
ZM( 44-46)B	105	Φ44~46	≥600	300/380	10~40	5~12	880	600
ZM( 46-48)	110	Φ46~48	≥600	300/380	10~40	5~12	1080	700

Specification about power pump pack of hydraulic rock splitter / Similar to Darda hydraulic stone splitter.

Poewr pump pack	Dimension (mm)	weight (kg)	Tank capability (L)	Engine power	pressure (MPa)	Flux (L/m)	Splitting (pc)
Diesel engine	1150*1180*940	120	40	6Hp	55-60	2-13	1-10

Photos Of Zm (32-38) Diesel Hydraulic Stone Rock Concrete Splitting Machine
